Oak Spiral Staircase East Sussex

Spiral Staircase East Sussex was a unique double flight spiral staircase supplied to a customer undertaking an oast house conversion.  Being a circular building, a spiral was the obvious solution when accessing the upper levels.  As the project was an extension to a larger building, the spiral we supplied was classed as a secondary spiral. To comply to building regulations, a 600mm clear tread width is required to meet this code which on this model means a 1500mm diameter. so a 1500mm diameter we supplied.

The model 71 spiral staircase is a bespoke spiral. It is constructed with circular barrels which slid over the centre column and separate the solid wooden treads The centre column which is hidden on completion has a steel column running up the middle giving the entire spiral staircase stability.

The wood available for this stunning spiral staircase in always hardwood for strength :- Beech, Oak, Ash, Maple, Birch & Walnut

The balustrade wrapping around the perimeter of the spiral is formed with :- Vertical Steel Spindles, Horizontal steel rails, Curved acrylic panels, Curved Glass Panels, Curved Perforated Steel Panels

The handrail and newel posts on the Model 71 spiral staircase are formed in timber or steel to match rest of the materials. The steel tends to be either brushed or polished stainless steel or powder coated. The wood is either oiled, varnished or stained in the factory and sometime left untreated to be stained on site.

Each Model 71 spiral staircase supplied is a one off. The spiral is drawn carefully to make sure the enter and exit point is correct and there are no headroom issues. As the spiral is bespoke, the platform can be made to suit the opening if needed and the overall outer diameter of the spiral can supplied upto 2200mm.

If you would like a price for this stunning spiral staircase, please fill out the form below.

Oak Spiral Staircase East Sussex

Technical Specification

Floor to floor height 2635mm & 2644mm
Risers 13 @ 202.69mm & 13 @ 203.38mm
Spiral Diameter 1500mm
Clear Tread Width 620mm
Tread Type 40mm Oak
Balustrade Type 16mm Ø Stainless Steel Spindles
Handrail 50mm Ø Oak handrail
Centre Column 139mm Ø
Finish of Steel Stainless steel
Additional Oak riser up stands and matching landing balustrade
